4 axis plasma cutting machine MS-TR
What is axis plasma cutting? How many axis do we need for cutting?
Axis plasma cutting is an advanced CNC (Computer Numerical Control) manufacturing process that involves moving the plasma head along an axis around the workpiece to cut and shape the material from different angles. Allows the operator to cut complex parts in a quick step and eliminates the need to disassemble, reorient and reinstall the workpiece after each plasma pass.
A standard 2-3 axis plasma cutter can only cut metal parts in 2D motion. Inherently restricts the operator from cutting flat metal. More directional axis movement allows for a high degree of flexibility in cutting, resulting in 3D (three-dimensional) cutting. The rectangle pipe plasma cutting need 4 CNC axis.
The plasma cutting head in a four-axis plasma cutter moves along the following axes.
X-axis: horizontal movement – left and right.
Y-axis: Horizontal movement – front and back.
Z-axis: Vertical movement – up and down.
A-axis: Horizontal rotation – Rotate on the X axis.
4 axis plasma rectangle pipe CNC cutting machine MS-TR introcution:
Multiple axis plasma cutting machine MS-TR is for rectangle and square cutting machine, it is one of our pipe profile CNC cutting machines.
4 axis Plasma Cutting Machine Advanced Structure:
1. Plasma cnc cutting way, can add gas cutting way, suitable for wall thickness 0.3-25mm.
2. Overall structure,ensure accuracy and good condition in long life.
3. Suitable for most metal square tube:40*40mm-240*240mm or customized.
4. 4 Axis, suitable for square pipes, rectangle pipes cutting.
5. CNC system has mulitple interface, say, English, Russian, Spainsh etc;
6. Visiable operation system, freely enter or exchange data, say diameter within the system, to achieve the parts that need to be cut.
7. Round pipe profile cutting function if need available to add.
4 Axis Plasma Cutting Machine Specification
